EVH 5150 Iconic Series 15W 6L6 Head Black

The 5150 Iconic Series 15W 6L6 Head condenses EVH’s high-gain amp platform into a compact all-tube head with two channels and 15 watts of output. Channel one covers Clean and Overdrive sounds, while channel two handles Lead and Burn, providing multiple gain ranges without requiring a larger-format 5150 head.

The tube complement consists of a single 6L6 power tube and two ECC83S preamp tubes. Each channel has dedicated Gain and Volume controls, while a shared three-band EQ handles Low, Mid and High. Global Reverb, Resonance and Presence provide additional shaping, and the included two-button footswitch gives access to channel switching and the 6dB Clean Input Stage Boost.

For lower-volume use, a quarter-power setting reduces available headroom for home and studio applications. The head also provides a speaker-emulated 1/8" stereo headphone output, 1/8" stereo line output, effects loop and dual parallel speaker outputs with selectable 4-, 8- or 16-ohm impedance.

The Black version uses textured vinyl covering with a black metal grille, silver anodized aluminum front panel and black chicken-head controls. At 19.7" wide and 18 pounds, it offers the core controls and connectivity of the Iconic platform in a portable head format.

Highlights

• 15-watt all-tube design with 6L6 power tube
• Two channels with Clean/Overdrive and Lead/Burn modes
• Quarter-power setting for reduced-volume operation
• Speaker-emulated stereo headphone output
• Effects loop and selectable 4/8/16-ohm speaker impedance

Specifications

Amplifier

• Amplifier Type: Tube
• Power: 15 Watts
• Channels: 2
• Channel 1: Clean/Overdrive
• Channel 2: Lead/Burn
• Channel 1 Controls: Gain with Overdrive Switch, Volume
• Channel 2 Controls: Gain with Burn Switch, Volume
• EQ: Shared Low, Mid, High
• Global Controls: Master Boost, Reverb, Resonance, Presence
• Power Reduction: Quarter-Power Setting
• Effects: Reverb

Tubes

• Power Tubes: 1 x 6L6
• Preamp Tubes: 2 x ECC83S

Connectivity

• Input: 1 x 1/4"
• Effects Loop: 1/4" Send/Return
• Headphone Output: 1/8" Stereo, Speaker Emulated
• Line Output: 1/8" Stereo
• Speaker Outputs: 2 x 1/4" Parallel
• Speaker Impedance: Selectable 4, 8 or 16 Ohms

Construction

• Covering: Black Textured Vinyl
• Cabinet Material: MDF
• Grille: Black Metal
• Front Panel: Silver Anodized Aluminum
• Control Knobs: Black Chicken-Head Style
• Handle: Molded Plastic Strap with Black Powder-Coated Caps
• Amplifier Jewel: Red LED

Miscellaneous

• Series: 5150 Iconic
• Color: Black
• Voltage: 120V
• Dimensions: 19.7" W x 10.2" H x 9" D
• Weight: 18 lbs.
• Country of Origin: Indonesia
• 2-Button Footswitch Included
