Fender John 5 Phantom Telecaster Black

The Fender John 5 Phantom Telecaster takes John 5’s long-running connection with the Telecaster platform and reshapes it around a high-output HH configuration, double-locking tremolo, and stripped-down controls. The Nyatoh body is finished in Black, with gloss urethane on the top and satin urethane on the back, while the matching black Telecaster headstock completes the monochromatic design.

The maple neck uses a Custom John 5 Medium “C” profile with a satin finish and traditional 25.5" scale. Fender’s detailed specifications list an ebony fingerboard with a 12" radius, 22 Narrow Tall frets, white dot inlays, and a 1.69" Floyd Rose Special locking nut. This combination gives the Phantom a substantially more modern playing setup than a traditional Telecaster.

A pair of DiMarzio D Activator humbuckers handles the electronics, with matching pickups in the neck and bridge positions. The control layout is deliberately minimal, consisting of a single master volume, three-position pickup toggle, and dedicated kill switch.

The Floyd Rose FRTS2000 double-locking two-point tremolo provides the bridge system, complemented by Deluxe cast/sealed locking tuners. Black hardware, a one-ply anodized pickguard, black pickup covers, and a signature neck plate complete this John 5 Artist Signature model.

Highlights

• John 5 Artist Signature Telecaster in Black with matching headstock
• Dual DiMarzio D Activator humbuckers
• Floyd Rose FRTS2000 double-locking tremolo
• Custom John 5 Medium “C” neck with 12" radius ebony fingerboard
• Master volume, three-way pickup selector, and kill switch

Specifications

Body

• Body Shape: Telecaster
• Body Style: Solid Body
• Body Material: Nyatoh
• Top Finish: Gloss Urethane
• Back Finish: Satin Urethane
• Color: Black

Neck

• Headstock: Telecaster
• Neck Material: Maple
• Neck Construction: 4-Bolt
• Neck Shape: Custom John 5 Medium “C”
• Neck Finish: Satin
• Fingerboard: Ebony
• Fingerboard Radius: 12"
• Frets: 22 Narrow Tall
• Position Inlays: White Dots
• Side Dots: White
• Scale Length: 25.5"
• Nut: Floyd Rose Special Locking
• Nut Width: 1.69"

Hardware

• Bridge: Floyd Rose FRTS2000 Double-Locking 2-Point Tremolo
• Tuning Machines: Deluxe Cast/Sealed Locking
• Hardware Finish: Black
• Pickguard: 1-Ply Anodized
• Pickup Covers: Black
• Control Knob: Black Speed
• Neck Plate: 4-Bolt Signature Neck Plate
• Strings: Nickel-Plated Steel .009–.042

Electronics

• Bridge Pickup: DiMarzio D Activator Humbucker
• Neck Pickup: DiMarzio D Activator Humbucker
• Pickup Configuration: HH
• Controls: Master Volume
• Pickup Selector: 3-Position Toggle
• Auxiliary Switching: Kill Switch

Miscellaneous

• Series: Artist Signature
• Orientation: Right-Handed
• Country of Origin: Indonesia
