DescriptionAs Heard on
Fender American Special Stratocaster® guitars

Characterized by their midrange chirp, crystalline highs and tight bass, Fender Texas Special™ Strat pickups feature an overwound single-coil construction that produces big Texas-blues tone.

Tonal Characteristics

• Enamel-coated magnet wire produces warmer vintage-style tones
• Middle pickup is reverse-wound to eliminate hum in pickup positions two and four
• Over-wound calibrated pickups deliver scorching output
• Staggered polepieces balance volume and output across every string
• Alnico 5 magnets add more focus and enhanced dynamics

Product Details

• Period-correct cloth wire and fiber bobbin construction
• Available with white pickup covers

Included Components

Fender Texas Special™ Strat pickups come with all parts needed for installation, including:

• Mounting screws
• Pickup height adjustment tubing
• Wiring diagram

Output Rating (Bass/Mid/Treble)

• Neck: 4/6/8
• Middle: 4/6/7
• Bridge: 8/6/7

Other Specifications

DC Resistance

• Neck: 6.2k ohms
• Middle: 6.5k ohms
• Bridge: 6.7k ohms

Inductance

• Neck: 2.4 henries
• Middle: 2.6 henries
• Bridge: 3.58 henries
