JAM Pedals Rattler mk.2

JAM Pedals Rattler mk.2

---

1) Overview

The JAM Pedals Rattler mk.2 refines and reimagines the ferocious tone of early ’80s distortion boxes, delivering a modern evolution of the classic RAT-inspired circuit. Known for its raw attitude and touch sensitivity, the Rattler has long been a favorite for players seeking amp-like saturation with dynamic response—and now it’s been re-engineered for even greater tonal versatility, reliability, and control.

At the heart of the mk.2 is a custom-designed op-amp developed by JAM Pedals to perfectly replicate the open, dynamic feel of the vintage LM308 while ensuring consistent production and long-term dependability. The addition of a Mid Boost footswitch introduces a powerful new tonal dimension, enhancing presence and articulation without simply increasing volume. Combine that with two distinct clipping modes, click-less switching, and customizable startup behavior, and the Rattler mk.2 delivers refined distorted elegance for players who demand character, control, and craftsmanship.

---

2) Highlights

• Custom JAM Pedals op-amp replicates vintage LM308 tone and response
• Selectable symmetrical or asymmetrical clipping for distinct saturation textures
• Independent Mid Boost footswitch with internal level and bass controls
• Click-less, noise-free switching with customizable startup power state
• Handcrafted analog distortion designed for dynamic, amp-like performance

---

3) Specifications

Body

• Construction: Heavy-duty metal chassis
• Finish: Custom graphic artwork
• Footswitches: Click-less true-bypass for Rattler and independent Mid Boost
• LEDs: Status indicators for both distortion and boost

Electronics

• Circuit Type: Analog distortion
• Op-Amp: Custom discrete-component design replicating LM308 behavior
• Clipping: Selectable asymmetrical (classic) or symmetrical (modern)
• Controls:

• • Level – Output volume

  • Gain – Distortion amount

  • Tone – High-frequency filter

  • Mid Boost – Independent pre-distortion tone enhancer (engaged via second footswitch)

• Internal Adjustments:

  • Boost Level (sets overall boost intensity)

  • Bass Content (adjusts low-end response of boost)

• Power: 9V DC center-negative (adapter only – no battery operation)
• Bypass: True bypass with silent relay switching
• Startup State: Selectable “On” or “Off” at power-up

Connectivity

• Input: 1/4” mono jack
• Output: 1/4” mono jack

Miscellaneous

• Designed for guitar and bass
• Handcrafted in Greece


---
